Specification
| Brand | HP |
| Model | Z240 |
Product Type
| Product type | Workstation |
Form Factor
| Form Factor | Mid-Tower |
Processor
| CPU Information |
Processor Base Frequency 3.40 GHz Max Turbo Frequency 4.00 GHz Total Cores 4 Total Threads 8 Intel® Turbo Boost Technology 2.0 Frequency‡ 4.00 GHz Cache 8 MB Intel® Smart Cache Bus Speed 8 GT/s TDP 65 W |
Memory
| Installed Memory | 16GB DDR4 |
| Memory Type |
Memory expansion slots 4 DDR4 memory slots Memory type supported DDR4, UDIMM (unbuffered), ECC and non-ECC Memory modes Non-interleaved for a single channel. Interleaved when both channels are populated. Memory speed supported 2133MT/s DDR4 Memory protection ECC available on data Maximum memory 64 GB Memory configuration 4GB, 8GB and 16GB non-ECC/4GB, 8GB and 16GB ECC unbuffered DIMMs are supported. ECC and non-ECC memory DIMMs cannot be mixed on the same system. PCI express connectors |
Hard Disk
| Storage Option |
STORAGE RAID Level RAID 0, RAID 1, RAID 10 Interface Type Serial ATA-600 Type none Interface Type SATA 6Gb/s Spindle Speed 7200 rpm Type HDD Interface Class Serial ATA HARD DRIVE (2ND) Typen one STORAGE CONTROLLER Interface TypeSerial ATA-600 Channel Qty 6 Type Serial ATA Installed Qty 1 |
| Installed Hard Disk | HDD SAS 3.5 |
GRAPHICS CONTROLLER
| Display Adapter |
QUADRO 4000 - 2GB DDR5 Supported Graphic Cards NVIDIA NVS 310 512 MB graphics NVIDIA NVS 315 512 MB graphics NVIDIA NVS 315 1 GB graphics NVIDIA NVS 510 2 GB graphics AMD FirePro W2100 2 GB NVIDIA Quadro K420 1 GB Graphics NVIDIA Quadro K620 2 GB Graphics AMD FirePro W5100 4 GB NVIDIA Quadro K620 4 GB Graphics AMD FirePro W7100 8 GB graphics NVIDIA Quadro K4000 8 GB Graphics |
NETWORKING
| Ports | Integrated Intel I219LM PCIe GbE Controller (Intel vPro with Intel AMT 11.0) |
POWER
| Power Options |
Type power supply Min Operating Temperature 41 °F Nominal Voltage AC 120/230 V (50/60 Hz) Max Operating Temperature 95 °F 80 PLUS Certification 80 PLUS |
DIMENSIONS & WEIGHT
| dimensions ( H x W x D) | 170 x 399 x 442 mm (6.7 x 15.7 x 17.4 in) |
OPERATING SYSTEM
| Pre Install Os |
OS Provided: Type Microsoft Windows 10 Professional 64-bit Edition OS Provided Microsoft Windows 10 Professional 64-bit Edition License Preinstalled OS Windows 10 |
SERVICE & SUPPORT
| Warranty | limited 03-month warranty |
