Specification
| Brand | Dell |
| Model | Dell PowerEdge R730 Rack Server |
Product Type
| Product type | Server |
Form Factor
| Form Factor | Rack-mountable - 2U |
Processor
| CPU Information |
Processor Intel® Xeon® processor E5-2600 v4 product family Processor socket: 2 2.5MB per core; core options: 4, 6, 8, 10, 12, 14, 16, 18, 22 Intel C610 series chipset |
Memory
| Installed Memory | 64GB DDR4 |
| Memory Type | Up to 3TB (24 DIMM slots): 4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s |
Hard Disk
| PERC H730 Integrated RAID Controller, 1GB Cache | |
| Storage Option |
RAID controllers Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA Drive bays Internal hard drive bay and hot-plug backplane: Up to 16 x 2.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA Up to 8 x 3.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA Maximum internal storage1HDD: SAS, SATA, nearline SAS SSD: SAS, SATA 16 x 2.5" – up to 29TB via 1.8TB hot-plug SAS hard drives 8 x 3.5" – up to 64TB via 8TB hot-plug NL SAS hard drives |
| Installed Hard Disk | 3 x 900GB SAS Hard Drive |
GRAPHICS CONTROLLER
| Display Adapter | Integrated Display Adapter |
EXPANSION / CONNECTIVITY
| Expansion Slots | Up to 7 x PCIe 3.0 plus dedicated PERC slot |
NETWORKING
| Ports | Embedded NIC4 x 1GbE, 2 x 10+2GbE, 4 x 10GbE NDC |
POWER
| Power Options |
Auto-ranging, Platinum efficiency 495W, 750W, 1100W AC or Gold efficiency 1100W DC2Titanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W, 1100W AC power supply; |
DIMENSIONS & WEIGHT
| dimensions ( H x W x D) | H: 8.73 cm (3.44 in), W: 44.40 cm (17.49 in), D: 68.40 cm (26.92 in) |
| Weight | 29.5kg (64.9lbs) |
OPERATING SYSTEM
| Pre Install Os |
OS Provided: Type Microsoft Windows 10 Professional 64-bit Edition OS Provided Microsoft Windows 10 Professional 64-bit Edition License Preinstalled OS Windows 10 |
SERVICE & SUPPORT
| Warranty | limited 01-month warranty |
