Specification
| Brand | Cisco Systems Inc |
| Model | WS-C2960X-24PS-L |
Performance
| RAM | 512MB SDRAM |
| Flash Memory | 128MB |
Form Factor
| Form Factor | Rack-mountable - 1U |
EXPANSION / CONNECTIVITY
| Expansion Slots |
Console ports USB (Type-B), Ethernet (RJ-45) Stacking cable Optional Power Redundancy Option (PWR-RPS2300) Voltage range (Auto) 110V-240V Power Consumption Operational 0.49KVA |
| Interfaces | Wired/Switching/Routing |
| Compatible Slots | 1 RJ-45 serial console port 1 RJ-45 out-of-band management port |
DIMENSIONS & WEIGHT
| dimensions ( H x W x D) | 44.5 cm x 36.8 cm x 4.5 cm |
| Weight | 10.65 Kg |
NETWORKING
| Ports | 24 x Ethernet 10/100/1000 Gigabit ports |
| Connectivity Technology | Forwarding bandwidth(Gbps) 108Gbps |
| Data Link Protocol | Forwarding Bandwidth 108Gbps |
| Data Transfer Rate | Switching Bandwidth 216Gbps |
| Features | LAN Base |
MISCELLANEOUS
| Mix Features |
Performance 1000 Mb Latency: < 5 µs 10 Gbps Latency: < 3 µs Throughput: up to 166.6 Mp/s Routing/Switching capacity: 224 Gb/s Routing table size: 12000 entries (IPv4), 6000 entries (IPv6) MAC address table size: 32000 entries |
POWER
| Power Options |
2 power supply slots 1 minimum power supply required (ordered separately) 1+1 (with optional power supply) |
SERVICE & SUPPORT
| Warranty | limited 03-month warranty |
